Dangerous goods packaging 200x180x360 mm (en: 2024BX6671)

Price on request

Dangerous goods packaging 200x180x360 mm (en: 2024BX6671)

Price on request

Delivery status: Are you interested? Contact us and let us send you an individual offer!

free shipping within Germany

environmentally conscious

with UN labelling for the shipment of dangerous goods

can be closed with filament tape

SKU:	2024BX6671
wave type:	C-flute (approx. 4 mm thick)
construction:	FEFCO 0201
Shippable as:	DHL package from 5 kgDPD package SGLS package S
heigh:	360
length:	200
width:	180
quality:	1.40
Item weight:	0,17 kg
inner dimension:	200 x 180 x 360 mm (l x w x h)
outer dimension:	208 x 194 x 385 mm (l x w x h)
volume:	12,96 L
girth:
filling weight for hazard class:	4GV-X: 6,3 kg \| 4G-X: 10 kg \| 4G-Y: 15 kg \| 4G-Z: 15 kg
package contains:
palett contains:	1000
pallet dimensions:	1,200 x 800 x 2,250 mm (l x w x h)

ArtNr. 2024BX6671 | Dangerous goods packaging 200x180x360 mm

Extremely strong cartons with UN marking for shipping dangerous goods according to 4G and 4GV.

Outer liner: kraft liner brown
closure: flap glued
versatile due to 4-fold approval 4G and additionally 4GV
suitable for road transport (ADR), as well as sea (IMDG-Code, ADNR), rail (RID) and air transport (ICAO-TI, IATA)
permissible for the packing groups: I(X) II(Y) III(Z)
depending on packing group, approved for different maximum gross weights (see table)
tested and approved for use as composite packagings with metal or plastic containers as inner packaging
can be sealed with filament tape (see printed sealing instructions)

If dangerous goods cartons 4G / 4GV are basically also approved for your dangerous goods and the desired transport route, please refer to the notes in the corresponding safety data sheet of the dangerous goods.

Our test laboratory is a recognized and approved test center for corrugated board packaging for hazardous goods.

Please note that a safety label must be applied according to the safety data sheet of your product. We offer labels on request. You can find the appropriate filament tape here.

When shipping by air freight, the printed UN marking must not be covered by adhesive tape or similar.

The BAM approval certificate can be found under Further Information.

Item no.	Lengthxwidthxheight	Filling weight - kg / for hazard class				Filling volume (L)
		4GV-X	4G-X	4G-Y	4G-Z
2022BX1119	175x155x215 mm	4	5	8	8	5,8

The sizes indicated are the internal dimensions of the carton, given in length x width x height.

The following applies in principle to 4G packaging:

Only the currently valid regulations apply to the shipment of dangerous goods and the use of dangerous goods packaging. The cartons are tested and approved for use as composite packaging with metal or plastic containers as inner packaging. This combination must meet the requirements of the legal regulations according to the approval certificate and must be proven and documented by a post-test.

We will be pleased to carry out this verification for you on request. Please contact us.

Hersteller:

BOXXCO GmbH & Co. KG, Heideweg 5, Deutschland, Kontakt: kontakt@boxxco.com

BAM approval certificate according to 4GV

BAM approval certificate according to 4G
